Jandy CS Filter

Cartridge Filters

Jandy CS Filter

The new Jandy CS filters provide the same great filtration as the Jandy/Zodiac Large Tank Filter series in a more compact body, for superior clarity at just half the size. The attractive and slim design will easily fit into even the smallest of pool equipment pads/areas/spaces. It is designed for use with Zodiac/Jandy’s Versa Plumb system, which allows it to easily connect with the rest of your Jandy/Zodiac pool equipment, all while using a minimal amount of space on the existing equipment pad.

The cartridge element on the Jandy CS cartridge filter is easily removed, making it quick and simple to clean and care for. The Jandy CS filter features easy grip ergonomic handles and extra large drain ports in a small, compact thermoplastic body, making maintenance more straight forward than ever before.

Filter Features:
  • Filter Area: 250 ft.
  • Design Flow Rate: .5 gym/ft
  • Maximum Flow: 125 gpm
  • 6 Hour Capacity: 45,000 gallons
  • 8 Hour Capacity: 60,000 gallons
  • Normal Start Up Pressure: 6-15 psi
  • Maximum Working Pressure: 50 psi
  • Cartridges Required: 1
  • Shipping Weight: 36 lbs.
  • Height: 42.5″
